Thermal Product Solutions Ships Gruenberg Cleanroom Ovens to Medical Industry

Posted: Jun 25, 2019

Thermal Product Solutions, a global manufacturer of thermal-processing equipment, announced the shipment of six (6) Gruenberg Cleanroom Ovens to the Medical Industry.

These Gruenberg unitized ovens has a maximum temperature rating of 149°C with work chamber dimensions of 26” W x 26” D x 34” H. The Gruenberg cleanroom ovens were constructed from a structural steel frame that supported the 304L stainless steel interior chamber liners and the 304 #4 polished stainless-steel exterior. All interconnecting struts are non-continuous which keeps the exterior cool.

The front-loaded cleanroom ovens utilized horizontal airflow, which maximizes heating rates and temperature uniformity of the product load. A circulation blower located in a conditioning plenum chamber on the bottom of the oven. The blower directs air through a semi-pierced panel on one side of the chamber and flows horizontally across the product. The air exits the work chamber on the opposite wall back through the plenum for reheating and recirculation.

“Gruenberg products are designed to meet the highest standards of safety specifications. These cleanroom ovens were designed to accommodate the customer’s existing robot and loading trays for the drying of very sensitive medical devices.” – Denny Mendler, Gruenberg Product Manager

Unique features of these Gruenberg truck-in ovens include:

  • Electric heat

  • Fully welded 304L stainless steel interior liner

  • Powered vertical door

  • Nitrogen atmosphere

  • CDA purge system

  • Mass flow control system

  • Graphite shaft seal

  • Internal cooling coil

  • Oxygen analyzer

  • Remote NEMA 12/IP54 control enclosure

  • Interconnecting wire harnesses

  • AB PLC

  • 2711 Panelview 1500 HMI

  • High limit thermostat

  • Circuit breaker disconnect switch

  • E-stop

  • Light tower with alarm

  • SCR power controller
